2003 Hyundai Avante II 1.5 MT Base Alfa
Hyundai Avante Problems
Instruction Handbook Manual
2009, I bought a used Hyundai Avante but it did
not come with the car handbook.I have been try...
Oil Engine type
2009, I want to know what is the best type oil
engine fit to Avante 16s 2009, I have used toda...
Question please
2009, 1.whene i want to increase the speed i
will hear a strange sound i asked some
technicien...
| Body type | Sedan |
|---|---|
| Power | 107 Hp |
| Engine Displacement | 1500 cm3 or 1.5L or 91.5 cu-in |
| Color | silver |
| Transmission Gearbox | Manual |
| Fuel Type | Gasoline |
| Drive wheel | FF |
| Mileage | 113131 Miles |
| Vin | KMHDM14AP4U****31 |
| Price (out of date) | $2259 |
Frequently Asked Questions | |
|---|---|
| What is the body type, 2003 Hyundai Avante II? | Sedan, 5 Seats, 4 Doors |
| What is the fuel economy, Hyundai Avante Sedan 2003? | 9 l/100 km |
| How fast is the car, Hyundai Avante XD 2003? | 182 km/h, 0-100 km/h: 12.4 sec |
| How much power, 2003 Hyundai Avante 1.5 MT Base Alfa? | 107 Hp |
| What is the engine size, Hyundai Avante II 2003 Sedan 1.5 MT Base Alfa (107 Hp)? | 1.5L or 1495cm3 |
| How many gears, What type is the gearbox, 2003 Hyundai Avante Sedan 1.5 MT Base Alfa (107 Hp)? | 5 speed Manual |
| What is the drivetrain, 2003 Hyundai Avante II? | Front |
| How long is this vehicle, Hyundai Avante Sedan 2003? | 4525 mm |
| How wide is the vehicle, Hyundai Avante XD 2003? | 1725 mm |
| What is the gross weigh, 2003 Hyundai Avante 1.5 MT Base Alfa? | 1780 kg |
| How much trunk (boot) space, Hyundai Avante II 2003 Sedan 1.5 MT Base Alfa (107 Hp)? | 415 l |
Hyundai Avante II XD 1.5 MT Base Alfa (107 Hp) 2003, 2004, 2005, 2006 Specs
General information | |
|---|---|
| Complectation name | 1.5 MT Base Alfa |
| Production start year | 2003 |
| Production end year | 2006 |
| Drive type | Front |
| Frame type | Sedan |
| Transmission type | 5 speed Manual |
| Engine volume, cc | 1495 |
| Frame name | XD |
| 0 to 100 time | 12.4 |
| Max speed | 182 |
| Clearance, mm | 160 |
| Manufacturing country | South Korea |
| Doors | 4 |
| Winter complectation | yes |
Vehicle generation | |
| Generation name | XD |
| Generation number | 2 |
| Facelift number | 1 |
| Production start year | 2003 |
| Production end year | 2006 |
Engine, transmission and steering specs | |
Engine specs | |
| Engine name | G4EC |
| Fuel | Petrol (Gasoline) |
| Engine type | In-line, 4-cylinder |
| Max power, hp | 107 |
| Max power RPM, rpm | 6000 |
| Max power, hp (kWt) / rpm | 107 (79) / 6000 |
| Max torque, N*m | 135 |
| Max torque RPM, rpm | 4500 |
| Max torque, N*m (kg*m) / rpm | 135 (14) / 4500 |
| Valves per cylinder | 4 |
| Bore, mm | 75.5 |
| Stroke, mm | 83.5 |
| Actuator valves | DOHC, 16-valve |
| Engine additional info | Distributed injection |
Fuel consumption | |
| City | 10.7 |
| Country side | 7.4 |
| Combined | 9 |
Steering | |
| Electric power steering | yes |
Dimensions | |
Frame dimensions | |
| Exterior length, mm | 4525 |
| Exterior width, mm | 1725 |
| Exterior height, mm | 1425 |
Interior dimensions | |
| Capacity | 5 |
| Seat rows | 2 |
Chassis dimensions | |
| Wheel base, mm | 2610 |
| Turning radius, m | 5.1 |
| Wheel spacing front | 1485 |
| Wheel spacing rear | 1475 |
Weight and permissible load | |
| Mass, kg | 1210 |
| Max capacity | 570 |
| Max. weight | 1780 |
Volumes | |
| Fuel tank capacity, l | 55 |
| Trunk volume | 415 |
Other | |
| Addinfo | Headlight adjuster Electric trunk lock Active antenna on the rear window Fabric seat upholstery |
Suspension specs | |
Suspension specs | |
| Front suspension | Independent, Spring McPherson |
| Rear suspension | Independent, spring multi-link |
| Suspension about | Adapted |
Wheel rims | |
| Disc | 15" |
Tires | |
| Front wheels | 185/65R15 |
| Rear wheels | 185/65R15 |
Brakes | |
| Front brake | Ventilated discs |
| Rear brake | Discs |
Exterior | |
Headlights | |
| Additional stop light | yes |
Interior | |
Steering wheel and center panel | |
| Tilt steering | yes |
Seats | |
| Front seats ajust | Height adjustment of the driver's seat |
| Full flat seats | Rear seat that folds down in 1/3 to 2/3 ratio |
Electric interior package | |
| Front seat heater | yes |
| Centralized door lock | yes |
| Power window front | yes |
Safety | |
Airbags | |
| Drivers airbag | yes |
| Passengers airbag | yes |
Children safety | |
| isofix bar | yes |
Active and passive safety | |
| Safety belt pretensioner | yes |
| Safety belt limiter | yes |
Electronic security and traffic control systems | |
| ABS | yes |
| Electronic Brake Distribution | yes |
Amenity | |
Microclimate | |
| Air conditioner | yes |
| Air filter | yes |
Audio systems | |
| Additional sound equipment | Audio equipment, 4 speakers |
Car safety | |
| Immobilizer | yes |
Driver Kit | |
| Spare tire | yes |
2003 Hyundai Avante II XD 1.5 MT Base Alfa (107 Hp) specs
|
This gave rise to disagreement from other motor manufacturers, and the name was standardized as "Elantra" worldwide in 2001. Between 1996 and 1998, the Elantra was marketed as the Bimantara Cakra (1.5litre petrol) and the Bimantara Nenggala (1.8litre petrol) in Indonesia. The Hyundai Elantra is listed as United States Environmental Protection Agency (EPA) Picks Ten Most Fuel Efficient Vehicles. The Elantra ranked #2 in 2006 and 2007 in the category of most fuel efficient sedans, and also was ranked as the most efficient non-hybrid mid-sized sedan. Hyundai Elantra SE awarded 2008 Consumer Reports "top pick". Hyundai Elantra SE was among the top 10 vehicles for 2008 unveiled in the magazine's issue. The magazine's annual ratings, based on road tests and predicted safety and reliability are considered highly influential among consumers. Hyundai Elantra earned Consumer Reports' 'excellent' rating in predicted reliability. Hyundai Elantra SE is Consumer Reports top-ranked 2008 vehicle amongst 19 other compacts and subcompacts (however, the less expensive GLS trim line, without the electronic stability control standard on the SE trim line, and with less sporty tires, was ranked closer to the middle of the group). Beating out such high-quality competitors as the Honda Civic, Toyota Corolla and Toyota Prius. » Read More About Hyundai Avante |
