| Body type | Minivan |
|---|---|
| Power | 130 Hp |
| Engine Displacement | 1800 cm3 or 1.8L or 109.8 cu-in |
| Transmission Gearbox | Automatic |
| Fuel Type | Gasoline |
| Drive wheel | 4WD |
| Mileage | 42874 Miles |
| Vin | ZGM15-****77 |
| Price (out of date) | $13715 |
Frequently Asked Questions | |
|---|---|
| What is the body type, Toyota Isis Minivan 2013? | Minivan, 7 Seats, 5 Doors |
| How much power, Toyota Isis DBA-ZGM15W 2013? | 130 Hp |
| What is the engine size, 2013 Toyota Isis 1.8 Platana 4WD? | 1.8L or 1797cm3 |
| How many gears, What type is the gearbox, Toyota Isis 2013 Minivan 1.8 Platana 4WD (130 Hp)? | Variator |
| What is the drivetrain, 2013 Toyota Isis Minivan 1.8 Platana 4WD (130 Hp)? | All wheel drive (4x4) |
| How long is this vehicle, Toyota Isis Minivan 2013? | 4640 mm |
| How wide is the vehicle, Toyota Isis DBA-ZGM15W 2013? | 1710 mm |
Toyota Isis DBA-ZGM15W 1.8 Platana 4WD (130 Hp) 2012, 2013 Specs
General information | |
|---|---|
| Production start year | 2012 |
| Production end year | 2013 |
| Frame type | Minivan |
| Drive type | All wheel drive (4x4) |
| Transmission type | Variator |
| Engine volume, cc | 1797 |
| Frame name | DBA-ZGM15W |
| Clearance, mm | 160 |
| Doors | 5 |
| Winter complectation | option |
| Steering locaton | right |
Vehicle generation | |
| Generation name | XM10 |
| Generation number | 1 |
| Facelift number | 2 |
| Production start year | 2009 |
| Production end year | 2017 |
Engine, transmission and steering specs | |
Engine specs | |
| Engine name | 2ZR-FAE |
| Fuel | Petrol (Gasoline) |
| Engine type | 4 cylinder DOHC |
| Max power, hp | 130 |
| Max power RPM, rpm | 6200 |
| Max power, hp (kWt) / rpm | 130(96)/6200 |
| Max torque, N*m | 161 |
| Max torque RPM, rpm | 4000 |
| Max torque, N*m (kg*m) / rpm | 161 (16.4) / 4000 |
| Eco type | 2005 emission regulation 75% reduction |
| Variable cylinder system | no |
| Max power, kw (ps) / rpm | 96?130?/6200 |
| Max torque, N*m (kg*m) / rpm (carsensor) | 161?16.4?/4000 |
| Start stop system | no |
Fuel consumption | |
| Achieve fuel efficiency standards | Compliance with the 2015 fuel consumption standard |
Transmission | |
| Shifter position | On the dashboard |
Steering | |
| Electric power steering | yes |
| Steereing gear type | Gear rail |
| Steering vgs vgrs | no |
Dimensions | |
Frame dimensions | |
| Exterior length, mm | 4640 |
| Exterior width, mm | 1710 |
| Exterior height, mm | 1670 |
| Exterior size (L x W x H), mm | 4640x1710x1670?mm? |
Interior dimensions | |
| Capacity | 7 |
| Seat rows | 3 |
| Interior size (L x W x H), mm | 2705x1470x1315?mm? |
| Interior length, mm | 2705 |
| Interior width, mm | 1470 |
| Interior height, mm | 1315 |
Chassis dimensions | |
| Wheel base, mm | 2785 |
| Front axle length, mm | 1480 |
| Rear axle length, mm | 1475 |
| Turning radius, m | 5.5 |
| Front/rear axis length | 1480/1475?mm? |
| Wheel spacing front | 1480 |
| Wheel spacing rear | 1475 |
Weight and permissible load | |
| Mass, kg | 1540 |
| Total weight | 1925 |
Volumes | |
| Fuel tank capacity, l | 60 |
Suspension specs | |
Suspension specs | |
| Front suspension | Independent, Spring McPherson |
| Rear suspension | Semi-independent, torsion bar |
| Sport suspension | no |
| Low down | no |
| Air suspension | no |
| Cenral diff lock | no |
| LSD | no |
| 4ws | no |
Wheel rims | |
| Aluminium wheel | yes |
| Magnesium wheels | no |
Tires | |
| Front wheels | 195/65R15 |
| Rear wheels | 195/65R15 |
| Run flat tires | no |
Brakes | |
| Front brake | Ventilated discs |
| Rear brake | Discs |
| Brakes equipment | no |
Exterior | |
Headlights | |
| Xenon lamps | no |
| Head lights washer | no |
| Front fog lamps | yes |
| Rear fog lamps | no |
| Rain sensor | no |
Side mirrors | |
| autocorrected mirrors | no |
Doors | |
| Side sliding door | no |
| Sliding doors | yes |
| Sliding electric door | yes |
| Sliding electric doors | no |
| Door easy closer | yes |
| Power rear door | no |
Windows | |
| Privacy glass | yes |
| Ultraviolet glass protection | yes |
Roof | |
| Sunroof | no |
| Big sunroof | no |
| T bar roof | no |
| Roof equipment | no |
| Targa roof | no |
| Hard top | no |
Accessories | |
| Roof rail | no |
| Front spoiler | yes |
| Rear spoiler | yes |
Body color | |
| Colors | 2453 2019 2041 2182 2629 2020 |
Interior | |
Steering wheel and center panel | |
| Engine start button | yes |
Interior design | |
| Water-repellent | no |
| Leather seat | no |
| Antibacterial repellent | no |
Seats | |
| Bucket seat | no |
| 2nd row | 60/40 ratio fold seat |
| 3nd row | 50/50 ratio fold seat |
| Seat lifter | yes |
| Full flat seats | |
| Removable seats | yes |
| Ottoman seat | no |
| Front bench seat | no |
| Walk throught | yes |
| 2nd row throught | no |
Electric interior package | |
| Power adjustable driver seat | no |
| Power ajustable front seat | no |
| Adjustable 3rd row | no |
| Front seat heater | no |
| Rear seats heater | no |
| Seat position memory | no |
| Keyless enter | yes |
| Power window | yes |
| Stearing wheel heater | no |
Additional interior equipment | |
| AC plug | no |
Safety | |
Airbags | |
| Drivers airbag | yes |
| Passengers airbag | yes |
| Side airbag | option |
| Curtain airbags | option |
| 2 airbags | no |
Children safety | |
| isofix bar | yes |
| Build-in child seat | no |
Active and passive safety | |
| Active headrest | no |
| Road Service | |
Electronic security and traffic control systems | |
| ABS | |
| Break assist | yes |
| ESP | yes |
| traction control | yes |
| Down hill assist | no |
| AYC | no |
| SH-4WD | no |
| Lane Keep Assist | no |
| Cruise control | no |
| Distance control system | no |
| Intelligent AFS | no |
| Night vision | no |
| Parktronic | no |
| Intelligent parking assist | no |
| Collision mitigation system | no |
Amenity | |
Microclimate | |
| Air conditioner | yes |
| Air purifier | no |
| Humidifier | no |
| Air filter | yes |
| Odor absorber | no |
Audio systems | |
| Radio | no |
| Autoreverse casette | no |
| CD player | no |
| DVD-audio | no |
| MD palyer | no |
| Audio HDD | no |
| Speaker | yes |
| Rear entertainment system | no |
Navigation and video equipment | |
| Full color LCD display | no |
| Navigation system | |
| Optional navigation system | no |
| Parking assist system | no |
| Front monitor | no |
| Sides monitors | no |
| Back monitor | no |
Additional amenities | |
| Lagage box | no |
| Etc | option |
Car safety | |
| Alarm system | yes |
| Security alarm | no |
2013 Toyota Isis DBA-ZGM15W 1.8 Platana 4WD (130 Hp) specs
|
