Body typeMinivan
Power97 Hp
Engine Displacement1500 cm3 or 1.5L or 91.5 cu-in
Colorwhite
Transmission GearboxAutomatic
Fuel TypeGasoline
Drive wheel4WD
Mileage86991 Miles
VinS412M-0****34
Price (out of date)$11668

Frequently Asked Questions

What is the body type, 2014 Toyota Town Ace IV?Minivan, 5 Seats, 5 Doors
What is the fuel economy, Toyota Town Ace Minivan 2014?8.6 l/100 km
How much power, Toyota Town Ace DBF-S412M 2014?97 Hp
What is the engine size, 2014 Toyota Town Ace 1.5 DX 4WD?1.5L or 1495cm3
How many gears, What type is the gearbox, Toyota Town Ace IV 2014 Minivan 1.5 DX 4WD (97 Hp)?Automatic transmission 4
What is the drivetrain, 2014 Toyota Town Ace Minivan 1.5 DX 4WD (97 Hp)?All wheel drive (4x4)
How long is this vehicle, 2014 Toyota Town Ace IV?4045 mm
How wide is the vehicle, Toyota Town Ace Minivan 2014?1665 mm

Toyota Town Ace IV DBF-S412M 1.5 DX 4WD (97 Hp) 2014, 2015, 2016, 2017, 2018 Specs

General information

Production start year2014
Production end year2018
Drive typeAll wheel drive (4x4)
Frame typeMinivan
Transmission typeAutomatic transmission 4
Engine volume, cc1495
Frame nameDBF-S412M
Clearance, mm175
Manufacturing countryIndonesia
Doors5
Winter complectationyes
Steering locatonright

Vehicle generation

Generation nameS400
Generation number4
Production start year2008
Production end year2020

Engine, transmission and steering specs

Engine specs

Engine name3SZ-VE
FuelPetrol (Gasoline)
Engine type4 cylinder DOHC
Has turbono
Max power, hp97
Max power RPM, rpm6000
Max power, hp (kWt) / rpm97 (71) / 6000
Max torque, N*m134
Max torque RPM, rpm4400
Max torque, N*m (kg*m) / rpm134 (14) / 4400
Compression ratio10
Bore, mm72
Stroke, mm91.8
Engine additional infoVVT, electronic fuel injection system

Fuel consumption

Combined8.6
Co2 emission200

Transmission

1st gear ratio2.73
2nd gear ratio1.526
3rd gear ratio1
4th fear ratio0.696
Rear gear ratio2.29
Main gear ratio5.125
Shifter positionOn the dashboard

Steering

Power steeringyes
Steereing gear typeGear rail

Dimensions

Frame dimensions

Exterior length, mm4045
Exterior width, mm1665
Exterior height, mm1900

Interior dimensions

Capacity5
Seat rows2

Chassis dimensions

Wheel base, mm2650
Front axle length, mm1460
Rear axle length, mm1440
Turning radius, m5.3
Wheel spacing front1460
Wheel spacing rear1440

Weight and permissible load

Mass, kg1290
Total weight2100
Max capacity700

Volumes

Fuel tank capacity, l43

Suspension specs

Suspension specs

Front suspensionIndependent, Spring McPherson
Rear suspensionDependent, on longitudinal arms
Cenral diff lockyes

Tires

Front wheels165R13LT
Rear wheels165R13LT

Brakes

Front brakeVentilated discs
Rear brakedrum brakes

Exterior

Headlights

Halogen headlightsyes
Rear fog lampsyes
Additional stop lightyes

Side mirrors

Power adjustable door mirrorsno

Doors

Sliding doorsyes

Windows

Privacy glassno
Rear glass heatyes

Accessories

Bumpersunpainted
Back wiperyes

Interior

Interior design

Combined obivka Salonyes

Seats

Front seats ajustbackrest tilt adjustment, longitudinal adjustment
2nd rowfoldable, backrest is indivisible

Electric interior package

Centralized door lockyes
Keyless enterno
Power window frontno

Additional interior equipment

Smokers packetyes

Safety

Airbags

Drivers airbagyes
Passengers airbagyes

Electronic security and traffic control systems

ABSyes

Amenity

Microclimate

Air conditioneryes

Audio systems

Additional sound equipment2 speakers

Car safety

Alarm systemno

Driver Kit

Spare tireyes
Jackyes
Balonnikyes


2014 Toyota Town Ace IV DBF-S412M 1.5 DX 4WD (97 Hp) specs

The Toyota TownAce (body type CR21) was introduced by Toyota in Japan in April 1983 as a short wheelbase mid-engined luxury 7/ 8 seat MPV resembling their Space Cruiser. A 4WD version (body type CR30) was introduced in December 1985. These were produced until a facelift in September 1993 to body type CR31 which ran until October 1996. It was available with either automatic transmission or manual transmission and petrol or diesel engine. Variants were badged as MasterAce (sometimes with "Surf" added) or LiteAce (sometimes with "FieldTourer" added). Top-end 7-seat TownAces were badged additionally "Royal Lounge". 8-seaters are often badged "Super Extra".


The left-hand drive Toyota Van for the USA market has a lot in common with the TownAce, but did not have all the luxury options, 4WD or the diesel engine.

When the TownAce models became available as grey market exports they became popular in UK, where new Spacecruisers had been sold for many years. A 10-year old TownAce was an attractive option for a reliable, cheap MPV with many luxury features - such as aircon/ climate control and automatic transmission. The 2CT diesel engine is low powered but offers 30+ mpg (less than 10 L per 100 km).

Large numbers were also exported to Russia and clusters are found in many other countries including Sri Lanka, Pakistan, Bangladesh, Tanzania etc.

UK grey import TownAce owners ran into two main issues — the need to keep the engine's ageing cooling system well-maintained and the lack of manuals or other documentation for doing any DIY repairs or maintenance. Websites and forums emerged to solve these problems and Toyota GB provided good support with supply of spare parts even though new TownAces had never been sold in UK. It happened that Toyota had produced a good repair manual (RM025E) for the 2CT diesel engine and Autodata had published a comprehensive TownAce manual, but only in Russian. Other information was gleaned from manuals for the related Toyota Van sold in USA and the Toyota Tarago sold in Australia.
