2009 Renault Kangoo II 1.5 dCi 90 FAP MT Happy Family
Renault Kangoo Problems
Renault Engine Failure
2005, i. Engine hunting at idle speed ii.
Temp indicator drop to zero and engine will cut
-...
| Body type | Minivan |
|---|---|
| Power | 90 Hp |
| Engine Displacement | 1500 cm3 or 1.5L or 91.5 cu-in |
| Color | white |
| Transmission Gearbox | Manual |
| Fuel Type | Diesel |
| Drive wheel | FF |
| Mileage | 129866 Miles |
| Vin | VF1FW0GB541****14 |
| Price (out of date) | $4381 |
Frequently Asked Questions | |
|---|---|
| What is the body type, 2009 Renault Kangoo II? | Minivan, 5 Seats, 5 Doors |
| What is the fuel economy, Renault Kangoo Minivan 2009? | 5.3 l/100 km |
| How fast is the car, Renault Kangoo KW0G 2009? | 160 km/h, 0-100 km/h: 16 sec |
| How much power, 2009 Renault Kangoo 1.5 dCi 90 FAP MT Happy Family? | 90 Hp |
| What is the engine size, Renault Kangoo II 2009 Minivan 1.5 dCi 90 FAP MT Happy Family (90 Hp)? | 1.5L or 1461cm3 |
| How many gears, What type is the gearbox, 2009 Renault Kangoo Minivan 1.5 dCi 90 FAP MT Happy Family (90 Hp)? | 5 speed Manual |
| What is the drivetrain, 2009 Renault Kangoo II? | Front |
| How long is this vehicle, Renault Kangoo Minivan 2009? | 4213 mm |
| How wide is the vehicle, Renault Kangoo KW0G 2009? | 1829 mm |
| What is the gross weigh, 2009 Renault Kangoo 1.5 dCi 90 FAP MT Happy Family? | 1955 kg |
| How much trunk (boot) space, Renault Kangoo II 2009 Minivan 1.5 dCi 90 FAP MT Happy Family (90 Hp)? | 438 l |
Renault Kangoo II KW0G 1.5 dCi 90 FAP MT Happy Family (90 Hp) 2009, 2010 Specs
General information | |
|---|---|
| Production start year | 2009 |
| Production end year | 2010 |
| Drive type | Front |
| Frame type | Minivan |
| Transmission type | 5 speed Manual |
| Engine volume, cc | 1461 |
| Frame name | KW0G |
| 0 to 100 time | 16 |
| Max speed | 160 |
| Clearance, mm | 183 |
| Manufacturing country | France, Turkey |
| Doors | 5 |
| Warranty | 2 years without mileage limit |
Vehicle generation | |
| Generation name | X61 |
| Generation number | 2 |
| Production start year | 2007 |
| Production end year | 2013 |
Engine, transmission and steering specs | |
Engine specs | |
| Engine name | K9K 808 |
| Fuel | Diesel |
| Engine type | In-line, 4-cylinder |
| Has turbo | yes |
| Turbo type | Turbine |
| Max power, hp | 90 |
| Max power RPM, rpm | 4000 |
| Max power, hp (kWt) / rpm | 90 (66) / 4000 |
| Max torque, N*m | 200 |
| Max torque RPM, rpm | 1750 |
| Max torque, N*m (kg*m) / rpm | 200 (20) / 1750 |
| Valves per cylinder | 2 |
| Compression ratio | 15.6 |
| Bore, mm | 76 |
| Stroke, mm | 80.5 |
| Engine additional info | SOHC |
| Eco type | Euro-4 |
Fuel consumption | |
| City | 6 |
| Country side | 4.9 |
| Combined | 5.3 |
| Co2 emission | 140 |
Steering | |
| Power steering | no |
| Electric power steering | yes |
Dimensions | |
Frame dimensions | |
| Exterior length, mm | 4213 |
| Exterior width, mm | 1829 |
| Exterior height, mm | 1819 |
Interior dimensions | |
| Capacity | 5 |
| Seat rows | 2 |
Chassis dimensions | |
| Wheel base, mm | 2697 |
| Turning radius, m | 5.35 |
| Wheel spacing front | 1521 |
| Wheel spacing rear | 1533 |
| Front overhang | 807 |
| Rear overhang | 709 |
Weight and permissible load | |
| Mass, kg | 1475 |
| Max capacity | 480 |
| Max. weight | 1955 |
| Max roof weight | 100 |
| Max towbar effort | 75 |
| Trailer max weight wobrakes | 740 |
| Loading height | 554 |
| Trailer max weight wbrakes | 1050 |
Volumes | |
| Fuel tank capacity, l | 60 |
| Trunk volume | 438 |
Other | |
| Addinfo | Folding tables on the backs of the front seats (optional) |
Suspension specs | |
Suspension specs | |
| Front stabilizer | yes |
| Front suspension | Independent, Spring McPherson |
| Rear stablilizer | yes |
| Rear suspension | Semi-independent, torsion bar |
Wheel rims | |
| Aluminium wheel | option |
| Front wheel disk | 15X6J |
| Rear wheel disk | 15X6J |
Tires | |
| Front wheels | 195/65 R15 |
| Rear wheels | 195/65 R15 |
Brakes | |
| Front brake | Discs |
| Rear brake | Discs |
Exterior | |
Headlights | |
| Halogen headlights | yes |
| Front fog lamps | yes |
| Rear fog lamps | yes |
| Additional stop light | yes |
| Light sensor | no |
| Rain sensor | no |
Side mirrors | |
| Exterior mirrors in body color | yes |
| Power adjustable door mirrors | yes |
| Door mirrors heating | yes |
Doors | |
| Side sliding door | no |
| Sliding doors | yes |
| Door handles in body color | no |
| Chrome door handles | no |
Windows | |
| Privacy glass | no |
| Termoglass | yes |
| Rear glass heat | yes |
Roof | |
| Tilt sunroof | option |
| Panoramic roof | no |
Accessories | |
| Roof rail | option |
| Bumpers | painted in body color |
| Back wiper | yes |
Body color | |
| Metallic paint Body | option |
Interior | |
Steering wheel and center panel | |
| Leather winding | no |
| Adjustable steering | yes |
| Telescopic steering | no |
| Tilt steering | yes |
| Audio control on steering wheel | option |
| Tachometer | yes |
Interior design | |
| Cloth upholstery | yes |
| Combined obivka Salon | no |
Seats | |
| Front seats ajust | In 6 directions. |
| 2nd row | 60/40 ratio fold seat |
| Seat lifter | yes |
| Headrests for seats | 5 |
| Separating armrest front | yes |
| Separating armrest rear | option |
| Seats pockets | yes |
| Mats | no |
Electric interior package | |
| Front seat heater | no |
| Centralized door lock | yes |
| Keyless enter | yes |
| Power window front | yes |
| Power window rear | option |
Additional interior equipment | |
| Smokers packet | yes |
| AC plug | yes |
Safety | |
Airbags | |
| Drivers airbag | yes |
| Passengers airbag | yes |
| Passenger airbag deactivation function with | yes |
| Side airbag | yes |
| Curtain airbags | option |
Children safety | |
| isofix bar | yes |
Active and passive safety | |
| Side impact bar | yes |
| 3 point safety belt | yes |
| Safety belt pretensioner | yes |
| Safety belt limiter | yes |
Electronic security and traffic control systems | |
| ABS | yes |
| Electronic Brake Distribution | yes |
| Break assist | yes |
| ESP | no |
| traction control | no |
| Cruise control | no |
| Autolock doors | yes |
| Function "Take me home" | yes |
| Rear sonars | no |
Amenity | |
Microclimate | |
| Air conditioner | yes |
| Automatic air conditioning | no |
| Air filter | yes |
Audio systems | |
| Radio | yes |
| CD player | yes |
| MP3 Support | option |
| Hands free | option |
| Additional sound equipment | 2 speakers |
Navigation and video equipment | |
| Full color LCD display | no |
| Navigation system | no |
Additional amenities | |
| Mirrors in sunshields | yes |
| Blind in luggage compartment | yes |
| Onboard computer | no |
Car safety | |
| Immobilizer | yes |
| Alarm system | option |
| Security alarm | option |
Driver Kit | |
| Spare tire | yes |
2009 Renault Kangoo II KW0G 1.5 dCi 90 FAP MT Happy Family (90 Hp) specs
|
The rear windows and seats can be removed, producing the panel van Kangoo Express. The Kangoo is popular with the mobility-impaired and wheelchair users due to its height and accessibility. It can be adapted to include mounting points for wheelchairs. Both the Kangoo and Kangoo Express are available in four-wheel drive versions, with raised ride height and altered styling. A lengthened version is also available, with an increased cargo area, as well as a pickup truck version in the Swedish market. In some countries, such as Malaysia, the Kangoo is assembled in the Nissan factory with a third row of 2 seats. The Kangoo was facelifted in 2003, resulting in the Phase II model. These vehicles are distinguished by their pronounced contemporary Renault nose design, with two gaping grille openings placed on either side of a suspended diamond badge. The headlamps were also restyled. The New Renault Kangoo and New Renault Kangoo Express are the new LCV generation in Renault. Based on Scenic and manufactured in Maubeuge, start of sales is Jan'08. A short wheel base version New Kangoo Compact, revealed at AMS2007 will come during spring'08. » Read More About Renault Kangoo |
