2004 Seat Ibiza III 1.4 MT Signo
Seat Ibiza Problems
Many fuel in km 160km/20litter
1992, my car take mutch fuel its takes 20
litters of gasoline for 160 kilometers and
black smo...
Jauge d'huile - type 02AD/5
1992, where is the "JAUGE
D'HUILE" in this seat. I can't
find it in my mo...
| Body type | Hatchback |
|---|---|
| Power | 75 Hp |
| Engine Displacement | 1400 cm3 or 1.4L or 85.4 cu-in |
| Color | black |
| Transmission Gearbox | Manual |
| Fuel Type | Gasoline |
| Drive wheel | FF |
| Mileage | 139965 Miles |
| Vin | VSSZZZ6LZ5R****04 |
| Price (out of date) | $1583 |
Frequently Asked Questions | |
|---|---|
| What is the body type, 2004 Seat Ibiza III? | Hatchback, 5 Seats, 5 Doors |
| What is the fuel economy, Seat Ibiza Hatchback 2004? | 6.4 l/100 km |
| How fast is the car, Seat Ibiza 6L 2004? | 174 km/h, 0-100 km/h: 13.2 sec |
| How much power, 2004 Seat Ibiza 1.4 MT Signo? | 75 Hp |
| What is the engine size, Seat Ibiza III 2004 Hatchback 1.4 MT Signo (75 Hp)? | 1.4L or 1390cm3 |
| How many gears, What type is the gearbox, 2004 Seat Ibiza Hatchback 1.4 MT Signo (75 Hp)? | 5 speed Manual |
| What is the drivetrain, 2004 Seat Ibiza III? | Front |
| How long is this vehicle, Seat Ibiza Hatchback 2004? | 3953 mm |
| How wide is the vehicle, Seat Ibiza 6L 2004? | 1698 mm |
| What is the gross weigh, 2004 Seat Ibiza 1.4 MT Signo? | 1552 kg |
| How much trunk (boot) space, Seat Ibiza III 2004 Hatchback 1.4 MT Signo (75 Hp)? | 267 l |
Seat Ibiza III 6L 1.4 MT Signo (75 Hp) 2002, 2003, 2004, 2005, 2006 Specs
General information | |
|---|---|
| Production start year | 2002 |
| Production end year | 2006 |
| Drive type | Front |
| Frame type | Hatchback |
| Transmission type | 5 speed Manual |
| Engine volume, cc | 1390 |
| Frame name | 6L |
| 0 to 100 time | 13.2 |
| Max speed | 174 |
| Clearance, mm | 161 |
| Manufacturing country | Spain |
| Doors | 5 |
| Winter complectation | option |
Vehicle generation | |
| Generation name | 6L |
| Generation number | 3 |
| Production start year | 2002 |
| Production end year | 2006 |
Engine, transmission and steering specs | |
Engine specs | |
| Engine name | AUA/BBY/BKY |
| Fuel | Petrol (Gasoline) |
| Engine type | In-line, 4-cylinder |
| Has turbo | no |
| Max power, hp | 75 |
| Max power RPM, rpm | 5000 |
| Max power, hp (kWt) / rpm | 75 (55) / 5000 |
| Max torque, N*m | 126 |
| Max torque RPM, rpm | 3800 |
| Max torque, N*m (kg*m) / rpm | 126 (13) / 3800 |
| Valves per cylinder | 4 |
| Compression ratio | 10.5 |
| Bore, mm | 76.5 |
| Stroke, mm | 75.6 |
| Actuator valves | DOHC |
| Engine additional info | Multipoint injection |
| Eco type | Euro-5 |
Fuel consumption | |
| City | 8.8 |
| Country side | 5.2 |
| Combined | 6.4 |
| Co2 emission | 153.6 |
Transmission | |
| 1st gear ratio | 3.455 |
| 2nd gear ratio | 2.095 |
| 3rd gear ratio | 1.387 |
| 4th fear ratio | 1.026 |
| 5th gear ratio | 0.813 |
| Rear gear ratio | 3.182 |
| Main gear ratio | 3.882 |
Steering | |
| Power steering | no |
| Electro-hydraulic power steering | yes |
Dimensions | |
Frame dimensions | |
| Exterior length, mm | 3953 |
| Exterior width, mm | 1698 |
| Exterior height, mm | 1448 |
Interior dimensions | |
| Capacity | 5 |
| Seat rows | 2 |
Chassis dimensions | |
| Wheel base, mm | 2460 |
| Turning radius, m | 5.3 |
| Wheel spacing front | 1435 |
| Wheel spacing rear | 1424 |
Weight and permissible load | |
| Mass, kg | 1057 |
| Max capacity | 495 |
| Max. weight | 1552 |
| Trailer max weight wbrakes | 800 |
Volumes | |
| Fuel tank capacity, l | 45 |
| Trunk volume | 267 |
Suspension specs | |
Suspension specs | |
| Front suspension | Independent, Spring McPherson |
| Rear suspension | Semi-independent, torsion bar |
Wheel rims | |
| Aluminium wheel | yes |
| Front wheel disk | 15X6J |
| Rear wheel disk | 15X6J |
Tires | |
| Front wheels | 195/50 R15 |
| Rear wheels | 195/50 R15 |
Brakes | |
| Front brake | Ventilated discs |
| Rear brake | drum brakes |
Exterior | |
Headlights | |
| Halogen headlights | yes |
| Xenon lamps | option |
| Head lights washer | yes |
| Front fog lamps | yes |
| Additional stop light | yes |
| Rain sensor | no |
Side mirrors | |
| Exterior mirrors in body color | yes |
| Power adjustable door mirrors | yes |
| Door mirrors heating | option |
Doors | |
| Door handles in body color | yes |
Roof | |
| Sunroof | option |
| Tilt sunroof | option |
Accessories | |
| Rear spoiler | yes |
| Bumpers | painted in body color |
Body color | |
| Metallic paint Body | option |
Interior | |
Steering wheel and center panel | |
| Leather winding | option |
| Adjustable steering | yes |
| Telescopic steering | yes |
| Tilt steering | yes |
| Env temp | option |
Interior design | |
| Cloth upholstery | yes |
| Leather upholstery | option |
Seats | |
| Bucket seat | no |
| 2nd row | 60/40 ratio fold seat |
| Seat lifter | yes |
| Seats pockets | yes |
Electric interior package | |
| Front seat heater | yes |
| Centralized door lock | yes |
| Keyless enter | option |
| Power window front | yes |
| Power window rear | yes |
| Injectors heat | yes |
Additional interior equipment | |
| Ashtray | yes |
Safety | |
Airbags | |
| Drivers airbag | yes |
| Passengers airbag | yes |
| Side airbag | option |
Children safety | |
| isofix bar | yes |
Active and passive safety | |
| Safety belt pretensioner | yes |
Electronic security and traffic control systems | |
| ABS | yes |
| Electronic Brake Distribution | option |
| ESP | option |
| traction control | yes |
| Cruise control | option |
Amenity | |
Microclimate | |
| Air conditioner | yes |
| Automatic air conditioning | option |
Audio systems | |
| Radio | yes |
| CD player | option |
| CD changer | option |
| Additional sound equipment | 4 speakers |
Navigation and video equipment | |
| Navigation system | option |
Additional amenities | |
| Onboard computer | yes |
| Light | Background illumination of the interior, trunk, cigarette lighter |
Car safety | |
| Immobilizer | yes |
| Security alarm | option |
| Bolt-card | option |
2004 Seat Ibiza III 6L 1.4 MT Signo (75 Hp) specs
|
The Ibiza Mk1 (codenamed 021A) was based on the SEAT Ronda, in turn derived from the Fiat Ritmo, with a powertrain which had been developed in collaboration with Porsche. This was the first SEAT which did not share any external body panels with any Fiat model, having been designed by Giorgetto Giugiaro. This version, while it established the now classic Ibiza shape, was advertised as having "Italian styling and German engines". It was known for having a rather quirky interior instrument layout, marked by a lack of control stalks. The indicators were operated by a rocker-switch and the headlights by a sliding switch. In terms of size, it was larger than most superminis like the Ford Fiesta and Fiat Uno, but smaller than any small family car such as the Ford Escort and Volkswagen Golf. Styling was fairly imaginative and interior space was good, but the Ibiza was let down by suspect build quality, heavy steering and doubtful reliability. SEAT also produced a saloon model based on the same platform, the SEAT Málaga. » Read More About Seat Ibiza |
